Modern Customized 2 Floors Steel Flat Pack House Container Home for living – Quality Integrated House
Modern Customized 2 Floors Steel Flat Pack House Container Home for living
| NO. | NAME | DESCRIPTION | SIZE | QTY | UNIT |
| 一 BASIC ITEM | 11 | set | |||
| 1 | Roof | color steel buckle plate | 0.5mm | 11 | set |
| glasswool insulation | |||||
| galvanized steel keel | |||||
| white metal ceiling | 0.3mm | ||||
| 2 | Floor | vinyl leather flooring | 1.6mm | 11 | set |
| cement fiber board | 1.8mm | ||||
| PE insulation film | |||||
| galvanized steel keel | |||||
| 3 | Column | glavanized steel column | L2580mm | 44 | pc |
| 4 | Drain pipe | Rain drain pipes | white pvc pipe | 44 | pc |
| 二INCREASE ITEM | |||||
| 5 | Wall panel | 75mm Glasswool sandwich panel | 321.75 | m2 | |
| 6 | Roof | 75mm Glasswool sandwich panel | 0 | m | |
| 7 | Exterior wall decoration | Hanging board | 180.5 | m2 | |
| 8 | Roof tile | Asphalt shingle | 0 | m2 | |
| 9 | Decking | WPC | 40 | m2 | |
| 10 | Guardrail | 13 | m2 | ||
| 11 | Stair | 1 | set | ||
| 12 | Window | Aluminium-alloy window | 46 | m2 | |
| 13 | Door | white steel door | 700mm*2000mm | 0 | set |
| 800mm*2000mm | 9 | set | |||
| Aluminium-alloy door | 13.84 | m2 | |||
| 14 | Electric system | change into local standard | 11 | set | |
| Led light | 18 | pc | |||
| switch | 20 | pc | |||
| socket | 27 | pc | |||
| 15 | Water system | inlet & outlet water pipes | 27.43 | m2 | |
| 16 | Assemble Accessories | PVC cover skirting | 11 | set | |
| Connection | module connection lock | 46 | set | ||
| Molding covering | module top and column connection part covering | 105 | m | ||
| module floor connection partcovering | 54 | m | |||
| sealing tape | rubber tape filling between module connection part | 87 | m | ||
| Self-glue tape | waterproof self glue tape between module connection part | 30 | m | ||
| NORMAL QUALITY | ||
| NO | ITEM | DESCRIPTION |
| 1 | bottom frame | beamthickness 2.5mm |
| secondary purlin C120*60*1.7mm | ||
| 50mm glasswool insulation | ||
| 0.23mmcovering tile | ||
| 2 | top frame | beamthickness 2.5mm |
| Z molding part | ||
| secondary purlin 80*40*1.3mm | ||
| 50mm glasswool insulation+PE film | ||
| 0.5mm steel sheet | ||
| 3 | column | 2526*210*150*2.5mm |
| 4 | floor board | 18mm fiber cement board |
| 5 | floor covering | 1.6mm PVC vinyle flooring |
| 6 | steel door | T75 0.6mm,size 845*2035 |
| 7 | PVC window | pvc sliding window 1130*1100 double glasses,flying screen |
| 8 | wall panel | V1150,75mm glasswool sandwich panel0.4/0.450KG/m³ |
| 9 | Accessories | φ50mmPVC pipes |
| 831*0.4mm ceiling | ||
| 75 channel | ||
| PVC skirting | ||
| 0.4mmcolumn cladding | ||
| rivet,screw,glue,etc. | ||
| 10 | Electric | Industry plug,distribution box,4 socket,1switch,2 light |
| 11 | Lifetime | 10 years |
